Specifications

Technical Data

Materials of Construction

Standard: A216 Gr. WCB, A351 Gr. CF8M; 1.0619, 1.4408

Options upon request: Duplex, Superduplex, LCC/LCB, WC6, CF3M, Monel®, Inconel®, Hastelloy®, Alloy 20; 1.4469, 1.7357, 1.4409, 2.4460

Size Range & Pressure Ratings

1/2” up to 12”

ASME Class 150, Class 300

Temperature Range

-40°F up to 800°F; -40°C up to 425°C, depending on valve type and material selection

Body Configurations

Flanged End, Long Pattern,

Floating Ball Design (1/2”-6”)

Trunnion Design (8”-12”)

Standards & Compliance

ISO 15848, Class BH, level CO2 is our standard offering

API 608 and ASME B16.34; EN 1983 valve design standard

Leakage as per FCI 70-2 Class VI or Class V (tested per API-598)

API 607, 7th edition; EN-ISO 10497 Fire Tested

EPA Method 21 (Fugitive Emissions Compliance)

TA-Luft compliance acc. to VDI 2440

API 641

Quality certification as per ISO 9001

CE-marking according to DGRL 2014/68/EU

ISO 5211 actuator mounting

SIL 2 and 3

CRN (Canada) certified

TSG (China) certified

EAC (Russia) certified

Special Options

Bearing protector

Industrial packing or high-temperature stem seal to meet ISO 15848, Class BH, level CO2 at 800°F/425°C

API 6D test is available upon request
